Technical parameters of LD type 32 tons electric single beam bridge crane

LD type 32 tons electric single beam bridge crane

32 ton electric single beam crane refers to LD type electric single beam bridge crane with rated lifting capacity of 32 tons. 32 ton single beam crane is rarely used in actual production. The editor will share the technical parameters and dimensions of 32 ton electric single beam crane.

LD type 32 tons electric single beam bridge crane

32 ton electric single beam crane structure diagram

32 ton electric single beam crane structure diagram

32 ton electric single beam crane dimensions table

Lifting capacitytSpan (m)Basic sizeTotal weight(t)Maximum wheel pressure(t)Minimum wheel pressure (t)
H1H2H3BC1C2C3
327.59002100130025001830123020005.75/5.3016.65/14.53.55/3.70
85.87/5.4016.70/14.83.60/3.90
8.56.15/5.5416.90/15.23.85/3.95
96.50/5.6517.20/15.84.22/4.15
9.57.35/5.8517.53/15.94.58/4.30
107.58/6.2017.90/16.45.10/4.70
10.57.90/6.3518.25/16.75.35/4.90
118.22/6.6818.45/16.955.48/5.15
11.59002100135030001830123025008.58/6.9518.68/19.365.66/5.35
128.96/7.2818.92/17.515.89/5.40
12.59.47/8.5619.37/17.835.86/6.30
139.95/8.8519.63/18.216.71/6.34
13.590021001350300018301230250010.55/9.2819.96/18.587.15/6.80
1410.80/9.6720.23/19.187.45/6.98
14.590021001300250018301230200011.60/9.9020.65/19.407.95/7.22
1511.94/10.3520.97/19.808.33/7.68
15.512.35/10.6521.38/20.208.58/7.956
1612.84/11.0521.60/20.558.78/8.28
16.590021001300300018301230250012.35/11.3822.10/20.809.11/8.85
1712.88/11.7022.55/21.109.45/9.18
17.5105021001450350017301230300013.55/12.1022.90/21.409.85/9.45
1813.96/12.4523.32/21.9010.31/9.80
18.514.45/12.7523.45/22.3210.76/10.22
1914.83/13.1223.86/22.7511.13/10.65
19.515.32/13.4524.27/23.1811.62/11.14
20110021001500350018301230320015.77/13.7624.77/23.6211.97/11.52
20.516.15/14.1525.28/24.1112.44/12.05
2116.40/14.5025.71/24.6312.73/12.43
21.516.98/14.8526.24/24.8513.55/13.06
2217.40/15.2326.68/25.2213.81/13.42
22.517.85/15.6826.93/25.6714.27/13.86
