3 Ton EOT Crane Price
How Much Does a 3 Ton EOT Crane Cost?
The price of a 3 ton EOT (Electric Overhead Traveling) crane typically ranges from $5,000 to $40,000, depending on span, lifting height, and customization. As a leading manufacturer with 20+ years of experience, Dongqi Crane provides cost-effective solutions that are 10-15% more affordable than European brands like Demag or Konecranes, without compromising quality.
Below is a detailed price breakdown for different configurations:
| Configuration | Basic Model (USD) | Premium Model (USD) |
|---|---|---|
| Standard (10m span, 6m height) | $6,500 | $12,000 |
| Variable Frequency Drive (VFD) | +$1,200 | +$2,500 |
| Explosion-Proof (Ex d) | +$4,000 | +$8,000 |
| Remote Control System | +$3,000 | +$5,000 |
| Custom Span (per extra meter) | +$500/m | +$800/m |
Prices exclude shipping and installation. Contact us for project-specific discounts.
5 Key Factors Affecting 3 Ton EOT Crane Price
1. Span Length
- Standard spans (5-30m): Each additional meter increases price by 5-8% due to heavier girders.
- Formula: Base Price + (Span Length × $500–$800/m).
2. Lifting Height
- Beyond 10m: Requires reinforced ropes/chain, adding $800–$1,200 per meter.
3. Duty Class (FEM/ISO Standard)
| Duty Class | Usage Intensity | Price Impact |
|---|---|---|
| A3 (Light) | <5 lifts/hour | Base Price |
| A5 (Medium) | 10-15 lifts/hour | +15% |
| A6 (Heavy) | Continuous use | +25-30% |
4. Brand & Components
- Dongqi Crane vs. European Brands:
- Motor: Dongqi uses Siemens/Teco (same quality, 20% lower cost).
- Steel: In-house produced Q345B beams reduce price by 12%.
5. Shipping & Installation
- Asia: Free shipping for orders >$20,000.
- Europe/USA: ~$3,000–$6,000 (door-to-port).
3 Ton EOT Crane Specifications for Warehouse Use – Dongqi Crane Solutions
When selecting a 3-ton Electric Overhead Traveling (EOT) crane for warehouse operations, key specifications such as span, lifting height, speed, and control systems directly impact efficiency and safety. Below is a detailed breakdown of Dongqi Crane’s warehouse-optimized EOT cranes, designed for high-frequency loading, narrow aisles, and long-term durability.
1. Core Specifications for Warehouse Applications
① Load Capacity & Span
- Rated Capacity: 3 tons (3,000 kg) – Can be customized up to 5 tons with reinforced structure.
- Span Range: 6m to 25m (standard warehouse spans: 8m–15m).
- Overhead Clearance: ≥200mm to maximize vertical storage space.
② Lifting Height & Speed
| Parameter | Standard Spec | High-Speed Option |
|---|---|---|
| Lifting Height | 6m–12m | Up to 20m (custom) |
| Lifting Speed | 8 m/min | 12 m/min (VFD) |
| Trolley Travel Speed | 20 m/min | 30 m/min |
| Bridge Travel Speed | 30 m/min | 45 m/min |
Note: Higher speeds require variable frequency drive (VFD) for smooth acceleration.
③ Duty Class & Usage Intensity
- FEM/ISO Duty Class: A3 (Medium Duty) – Suitable for 10–15 lifts/hour.
- Motor Protection: IP55 (dust-proof & water-resistant) for humid warehouse environments.
2. Warehouse-Specific Design Features
① Space-Saving Structure
- Low-Headroom Design: Reduces hook approach height by 15% vs. conventional cranes.
- Single/Double Girder Options:
- Single Girder: Ideal for spans <15m, lighter, and 10% cheaper.
- Double Girder: Better for 15m+ spans, higher precision (e.g., automated warehouses).
② Control Systems for Precision Handling
- Standard: Pendant control (8-button, 24V safety voltage).
- Advanced Options:
- Radio Remote Control (up to 100m range).
- Automated Positioning (±5mm accuracy for pallet racking).
③ Safety & Compliance
- Limit Switches: Upper/lower travel limits to prevent overloading.
- Overload Protection: 105% capacity cutoff.
- Certifications: CE, ISO 9001, OSHA-compliant.
3. Material & Build Quality
| Component | Dongqi Standard | Competitor Comparison |
|---|---|---|
| Main Girder | Q345B steel (yield strength ≥345MPa) | Some use Q235 (lower strength) |
| Hoist Wire Rope | ISO 2408 Grade 8 (2,160 MPa) | Cheaper Grade 6 ropes common |
| Wheels & Rails | 55Mn forged wheels, QU70 rails | Some use cast wheels (less durable) |
Dongqi’s cranes offer 50,000+ load cycles before major maintenance.
4. Ideal Warehouse Applications
- Palletized Goods Handling: Compatible with forklift-free workflows.
- High-Bay Storage: Supports 12m+ lifting heights for multi-level racks.
- Cold Storage Warehouses: Optional low-temperature lubrication (-30°C).
5. Why Dongqi for Warehouse Cranes?
✅ 10% Lower Lifetime Cost – In-house steel production reduces pricing.
✅ 3-Month Lead Time – Faster than industry average (6 months).
✅ Smart Upgrades Available – IoT-enabled load monitoring, predictive maintenance.
Real-World Case Study
Project: Automotive Assembly Line in Vietnam
- Quantity: 20 × 3 ton EOT cranes
- Specs: 22m span, 12m height, VFD control
- Savings: $120,000 vs. European supplier quotes
- Delivery: 35 days from order to installation.
“Dongqi’s cranes reduced our downtime by 40% with their smooth VFD operation.” — Eric Pham, Plant Manager
